Mytek Digital Brooklyn Amp+ Headphone Amplifier
Mytek Digital Brooklyn Amp+ Headphone Amplifier
Mytek Digital Brooklyn Amp+ Headphone Amplifier
Amplifier type
More information
Translation missing: en.products.product.amplifier_type_info
Solid-state
Connectivity
More information
Connectivity refers to the method in which the headphones connect to the audio source. Headphones can be either wired or wireless.
Wired
Portability
More information
DACs and amplifiers can either be carried around or meant for static desktop use
Not Portable
Description
BROOKLYN AMP+
COMPACT • HI-RES • DUAL MONO POWER AMPLIFIER
Experience the triode analog like quality of this compact powerful newest generation Class D amplifier from Mytek: Fast 650kHz clock extends bandwith, while fast FET transistors retain the low level detail and soundstage.
Amplifier is packaged in miniature 1/2 rack enclosure and it’s small enough to fit in a briefcase, yet powerful to drive the largest speaker systems. It’s designed to be used as regular stand-alone power amplifier or to complement Brooklyn Bridge for complete modern digital streaming and vinyl playback system. Two Brooklyn Amps work great in a monoblock setup in a bridge mode capable of driving very large speakers with 600W of power.
SPECS
-
POWER RATINGS AT 1% THD:
at 8 Ohm - dual mono 2 x 250 W
at 4 Ohm - dual mono 2 x 300 W
Peak - dual mono 2 x 1200 W -
BRIDGE MONO
8 Ohm / 500W 4 Ohm / 600W
-
OUTPUT SWING
57 Vp / 114 Vpp (unloaded)
-
SNR
>121 dB
-
FREQUENCY RESPONSE
-3dB: 10Hz - 30kHz
-
THD REGULAR USE
<0.001%
-
PROTECTION CIRCUITRY
Short circuit protection, DC protection, under voltage protection, temperature protection, overload protection
-
DAMPING FACTOR
>400
-
DC POWER ON TRIGGER
12VDC minijack
-
WORLDWIDE POWER SUPPLY
100-240VAC 50/60 Hz
-
DIMENSIONS
WxDxH=8.5x8.8x1.74”=216x225x44mm
-
WEIGHT
6lbs, 3kg
-
WARRANTY
2 years
